Speed Controller Valve-PA

No. d'article: PA04/PA06/PA08/PA10/PA12
Speed Controller Valve
Pneumatic Connectors
One Touch Tube Fittings
ENQUETE
Description

SPEED CONTROLLER-PA

◎ FEATURES
ㆍAccurate regulation of an optimal airflow rate for precise motion control.
ㆍCompact and space-saving configuration provides a functionally wide range of airflow rates.
ㆍAvailable in control method type for metering of unidirectional airflow either entering into or exhausting out of a driving device.

◎ SPECIFICATIONS


Applicable Fluid Type Air, Water(No Drinking Water)
Working Pressure Range -14~150 PSI -0.99~9.9Kgf/m?('-99~990Kpa)
Negative Pressure -29.5 in Hg(-14PSI) -750mmHg(-750Torr)
Working Temperature Range 23~140℉ (Air) 32~104℉ (Water) -5~60℃ (Air) 0~40℃ (Water)
Recommanded Tubings PA11, PA12, PA6, PE, PU,FEP,PFA

SPEED CONTROLLER-PA

PA Speed Controller Valve Fittings-Metric Tube

Item Code Tube Size(mm)
PA04 6
PA06 8
PA08 8
PA10 10
PA12 10

PA Speed Controller Valve Fittings-Inch Tube

Item Code Tube Size(Inch)
PA 5/32 5/32
PA 1/4 1/4
PA 5/16 5/16
PA 3/8 3/8
PA 1/2 1/2
